WebGLASME B31.3 · ISO 9606
Pipe Cutter Visualizer
Preview saddle intersections, adjust offsets, and export DXF templates ready for CNC plasma or waterjet tables.
- Realtime 3D preview
- DXF saddle export
- Offset + bevel controls
CAD AutoScript
CAD AutoScript is a streamlined hub for fabrication automation.
It handles essential design tasks - including pipe saddle visualization, DXF exports, PDF package processing, and instrumentation configurators. Every tool operates locally client-side (WASM), providing zero-latency performance and complete data security. Includes comprehensive documentation and a mini-games arcade.
Live utilities17
RuntimeChromium + WASM
FormatsDXF / SVG / CSV / PDF / JSON
Utilities
Just the essentials
Each utility is a standalone static app hosted under /utilities/*. Launches open the same pages machinists already know.
CalcEN 13445 · ASME VIII
Cylindrical Shell Rolling
Calculate roll spacing, bending allowance, and developed lengths with EN 13445 / ASME VIII presets.
- Roll spacing hints
- Printable offsets
- Tolerance guidance
CanvasISO 2768 · EN 10149
Sheet-metal bending sandbox
Simulate K-factors, reliefs, and bend deductions before locking in CAM programs or tooling.
- K-factor tuning
- Press brake presets
- Metric + inch
DataISO 965 · UNC/UNF
Interactive thread atlas
Filter ISO, UNC, and UNF series, reference drill diameters, and copy callouts for drawings.
- Filterable tables
- Drill lookup
- Copy-ready callouts
WASMOffline parsing
PDF number extractor
Highlight QA serials, BOM IDs, and inspection numbers locally with WASM-powered parsing.
- Regex filters
- CSV export
- Works offline
WebGL + QRTraceability - ISO 3864
3D QR nameplate generator
Model serialized equipment tags with QR codes, then preview thickness, materials, and engraving depth in real time.
- Three.js preview
- Material presets
- QR + engraving texture
CanvasDXF R12
WebDXF editor
Trim geometry, annotate lengths, and resave DXF files directly in the browser for quick QA or macro testing.
- Crossing selection
- Trim + measure
- Offline DXF I/O
PDF toolkitOffline processing
PDF Master
Organize drawing packs, reorder or rotate single sheets, and export a clean merged PDF locally.
- Drag & drop reordering
- Merge multiple PDFs
- Rotate individual pages
- View pages in original file
PDF-lib + JSZipLocal signing
PDF Batch Signer
Stamp a reusable signature across every page in multiple PDFs with one placement preview.
- Draw or upload signature
- Drag placement once
- ZIP export
Camera + QROffline
QR Master
Scan QR codes and barcodes instantly, generate custom codes for links or WiFi, and manage your scan history locally.
- Scan QR & barcodes
- Generate Wi-Fi/link codes
- History with import/export
- Smart paste & image scan
React + PDF.jsClient-side parsing
PDF BOM Extractor
Extract BOM and specification tables from CAD PDFs into clean CSVs with optional master report export.
- Smart table detection
- Auto-trim footers/revisions
- Per-file CSV + master report
ReactLocal-only
Batch File Renamer
Bulk rename files with find/replace, prefixes, numbering, and instant ZIP export.
- Regex or literal find/replace
- Prefix/suffix + numbering
- ZIP download with conflicts handled
React + JSZipClient-side
Folder Structure Builder
Design folder trees, import JSON or ZIP, and export bash/PowerShell scaffold scripts.
- JSON/ZIP import
- Bash/PowerShell scripts
- ZIP + JSON export
React + SVGDIN / EN + ASME / ANSI
Magnetic Level Gauge Configurator
Configure magnetic level gauge connections, dimensions, and options, then export a PDF datasheet.
- Process connection presets
- Live SVG sketch
- PDF datasheet export
React + SVGEN 837-1 / 837-2
Bourdon Gauge Configurator
Configure Bourdon tube pressure gauges with ranges, connections, accessories, and export a PDF spec sheet.
- Range presets + custom span
- Connection/accessory options
- Live gauge preview
- PDF export
React + SVGEN 13190
Industrial Thermometer Configurator
Configure bimetal thermometers: ranges, stems, thermowells, connections, and export a PDF datasheet.
- Range presets + custom
- Stem + thermowell options
- Adjustable mounting preview
- PDF export
SVG + CalcDIN 28011 / DIN 28013 / SS 895
Dished End (Vessel Head) Calculator
Size DIN 28011 / 28013 dished heads, preview dimensions, add nozzle callouts, and print a QC worksheet.
- Instant geometry preview
- Nozzle offset callouts
- Printable QC report
Documentation
Embed and explain inside MDX
Drop calculators into MDX, capture screenshots, or write run-books. The docs and utilities ship together so the interface stays small and predictable.
